Tuesday, May 01, 2018

Linux configuration for MySQL Cluster

NDB Cluster was designed from the ground up for real-time operations.
It has its origins in the telecom industry where predictability of performance
and latency is absolutely critical. In addition the telecom vendors are
competing very much on pricing of their product.

This leads to that it is important to get the most performance from each
telecom server. Increasing the performance by 10% means that you need 10%
less network equipment. If many servers are shipped this can be a substantial
cost that is worth spending valuable engineering time to achieve.

Thus if you are using or are planning to MySQL Cluster on many servers it
is a good idea to spend some time ensuring that one achieves optimal
performance. If you are operating MySQL Cluster in just a few servers the
payback on your time investment might not be as high.

Another reason to take a deep interest in performance of MySQL Cluster is
of course that you want to learn more about Linux and MySQL Cluster.

In this blog post I will mainly discuss one specific optimisation that can have
large impact on your performance. This is placing the execution threads of
MySQL Cluster and Linux on to the proper CPUs.

In my book MySQL Cluster 7.5 inside and out I devote 3 chapters to this
topic. One chapter on the usage of hyperthreading in data nodes, one
chapter on configuration of CPU locking for data nodes in NDB and
one chapter on configuring Linux interrupt handling.

In this blog post I will mainly discuss the Linux configuration.

NDB is a distributed DBMS where all operations pass through the network,
thus network operations is an essential part of the setup of a MySQL Cluster.

So how does a network packet arrive from the wire into MySQL Cluster and
out again.

The first thing that happens is that the network card receives a packet. It now
needs to inform a CPU about this packet such that Linux TCP/IP code can
handle the packet.

Now the Linux TCP/IP is divided into 3 parts. The first part is handling the
HW interrupt from the network card, the second part is handling the
soft interrupt. The final part is a function call interrupt from the soft interrupt
to the device driver to handle most of the interrupt handling.

The function call interrupt part was introduced in Linux 2.6.35, thus in older
Linux kernels this concept doesn't exist.

Modern Linux kernels also use the NAPI mechanism, this means that the
HW interrupt is disabled during the time we process a set of HW interrupts.
This mechanisms avoids overloading the CPUs with interrupt handling and
takes care of interrupts in batches at high load.

Now Linux interrupt setup is highly configurable and the defaults depends
among other things on the Linux distribution.

There are three main areas that can be configured for Linux. These are
RSS (Receive Side Scaling), RPS (Receive Packet Steering) and
RFS (Receive Flow Steering).

RSS handles setup of the HW interrupt and the soft interrupt. Often the
default is to spread these interrupts on all CPUs. This is usually not a
good idea for MySQL Cluster since some of the CPUs we want to
protect as much as possible from all OS activity (these are in particular
the LDM threads).

RPS is the new mechanism introduced in Linux 2.6.35 and one can configure
the CPUs where the function call interrupts are handled.

Finally RFS tries to ensure that the function call interrupt is executed
on the same CPUs where the application calls recv from. In NDB data nodes
this happens in the recv threads. In a MySQL Server the communication
from the data nodes arrives in the NDB API receive threads (this can be
configured to be locked to a specific CPU). The communication from MySQL
clients arrive in the connection thread where they are executed, so these are
spread on all CPUs the MySQL server is executing on.

When the NDB data node has processed the messages arriving on the network
it will send some responses onto the network. In the NDB data nodes this
happens either in all the threads or it happens in a send thread or a combination
of the two.

Linux has the possibility to configure transmit interrupts as well through
something called XPS (Transmit Packet Steering). The optimal behaviour is
achieved if the transmit interrupts are handled by the same CPU as the send
call is done from.

Configuring Linux and MySQL Cluster together can have a major positive
impact on performance. To achieve the best performance it is important to
consider the flow of data through the servers to process the database requests
from NDB clients (e.g. the MySQL Server).

Saturday, March 17, 2018

NDB Cluster and disk columns

NDB is mainly an In-memory database. We have however also the possibility to
store non-indexed columns on disk. This data uses a page cache as any
other normal disk-based DBMS.

Interestingly with the increases of memory sizes one could think that
disk data becomes less important for MySQL Cluster. The answer is actually
the opposite.

The reason is again the HW development. NDB is designed with predictable
latency as a very basic requirement. In the past disks meant hard drives. Access
time to a hard disk was several milliseconds at best. Given that our requirement
was to handle complex transactions within 10 milliseconds disk data storage
was out of the question.

Modern HW is completely different, they use SSD devices, first attached through
the SATA interface that enabled up to around 500 MByte per second and
a few thousand IO operations per second (IOPS). The second step was the
introduction of SSD devices on the PCI bus. This lifted the performance up to more
than  1 GByte per second. These devices are extremely small and still very powerful.
I have an Intel NUC at home that has two of those devices.

Thus the performance difference between disk storage and RAM has decreased.

The next step on the way was to change the storage protocol and introduce NVMe
devices. These still use the same HW, but use a new standard that is designed for
the new type of storage devices. Given those devices we have now the ability to
execute millions of IOPS on a standard server box with access times of a few tens
of microseconds.

For NDB this means that this HW fits very well into the NDB architecture. The work
we did on developing the Partial LCP algorithm did also a lot of work on improving
our disk data implementation. We see more and more people that use disk data
columns in NDB.

The next step is even more interesting, this will bring storage into the memory bus and
access times of around one microsecond. For NDB this disk storage can be treated as
memory to start with, thus making it possible to soon have multiple TBytes of memory
in standard boxes.

Thus HW development is making the NDB engine more and more interesting to use.

One notable example that uses disk data columns in NDB is HopsFS. They use the
disk data columns to store small files in the meta data server of the HopsFS
implementation of the Hadoop HDFS Name Server. This means much faster
access to small files. The tests they did showed that they could handled hundreds
of thousands of file reads and writes per second even using fairly standard SSD disks
on the servers.

The implementation of disk data in NDB is done such that each row can have three
parts. The fixed memory part that is accessed quickly using a row id. The variable
sized part that is accessed through a pointer from the fixed size part.

The disk columns are also accessed through a reference in the fixed size part. This
reference is an 8-bit value that refers to the page id and page index of the disk

Before we can access those pages we go through a page cache. The page cache was
implemented on caching techniques that was state of the art a few years ago.

The idea is quite simple. The page cache uses a normal hot page queue. Pages are
brought up in this queue when they are accessed. A single access will bring it up,
but to be more permanent in the page cache a page has to be accessed several times.

Now each page is represented in those queues by a page state record. The basis
of the page cache algorithm is that a page can be represented in a page state
record even if the page is not in the page cache.

NDB has a configuration variable called DiskPageBufferEntries, by default this is
set to 10. It is the multiplication factor of how many more pages we have
page state records compared to the amount of pages we have in the page cache.

So for example if we have set DiskPageBufferMemory to 10 GByte and we have
set DiskPageBufferEntries we will have page state records that holds pages of
100 GBytes in the queues. Thus even when a page is paged out we keep it in the
list and thus we can see patterns of reuse that are longer than the page cache
we have access to. The factor of 10 means that the page state records are of
about 3% of the size of the page cache itself. Thus the benefits of the extra
knowledge about page usage patterns comes at a fairly low cost. The factor
10 is configurable.

Many cloud servers comes equipped with hundreds of GBytes (some even TBytes)
and can also store a number of TBytes on NVMe devices. NDB is well suited
for those modern machines and MySQL Cluster 7.6 have been designed to be
suitable for this new generation of HW.

Friday, March 16, 2018

Discovering rows that have been updated since last checkpoint

One important problem that requires a solution is to decide whether
a row has been updated since the last checkpoint or not.

Most implementations use some kind of mechanism that requires extra
memory resources and/or CPU resources to handle this.

NDB uses the fact that each row is already stamped with a timestamp.
The timestamp is what we call a global checkpoint id. A new global
checkpoint is created about once every 2 seconds (can be faster or
slower by configuration).

Thus we will overestimate the number of rows written since last checkpoint
with a little bit, but with checkpoints taking a few minutes, the extra overhead
of this is only around 1%.

Thus when we scan rows we check the global checkpoint id of the row, if
it is bigger than the global checkpoint that the last checkpoint had fully
covered we will write the row as changed since last checkpoint. Actually
we also have the same information on the page level, thus we can check
the page header and very quickly scan past an entire page if it hasn't been
updated since last checkpoint.

The same type of scanning is used also to bring a restarting node up to
synch with the live node. This algorithm has been present in NDB since
MySQL 5.1.

Partial LCPs and Read-only tables

In MySQL Cluster 7.5 we use Complete Checkpoints. In MySQL Cluster 7.6
we implement an approach where we only checkpoint a part of the database
in each checkpoint.

A special case is a checkpoint of a table partition where no changes
at all have happened since the last checkpoint. In this case we implemented
a special optimisation such that it is not necessary to checkpoint anything
at all for this table partition. It is only necessary to write a new LCP
control file which is 4 kBytes in size for each table partition (can grow to
8 kBytes if the recovery will require more than 980 checkpoints to

This means that if your database contains a large set of read-only tables,
there will be no need to checkpoint those tables at all. This feature
is used also when setting EnablePartialLcp to false.
